Terminator X1

The Best 7x6 Headlight Upgrade, Period

The Terminator X1 replaces dim 7x6 (5x7) sealed-beam headlights with a DOT-approved, street-legal LED projector assembly. Triple projector lenses give a crisp beam cut-off that puts light on the road — not in oncoming drivers' eyes — and authentic CREE XM-L2 LEDs deliver 2,394 lumens on low and 3,898 on high per assembly.

15-Minute Install

Fits most vehicles running H6014 / H6052 / H6054 / 6054 sealed beams with little to no modification — trucks, vans, and classics alike. If the back of your headlight bucket has limited space, minor trimming may be required.

Specifications

• 45W — low and high beam in one assembly
• 2,394 lumens low / 3,898 lumens high per assembly
• Authentic CREE XM-L2 LEDs, 3x projector lens with clean cut-off
• DOT approved — street legal
• Die-cast aluminum housing, UV-resistant polycarbonate lens, IP68
• 9V–32V DC input — up to 50,000-hour lifespan
• 3" D x 7" W x 6" H, 2.8 lbs — black or chrome housing

Terminator X1 FAQ

Round headlights instead? See the Terminator D1 and D2 7-inch rounds.

Will it outlast an HID kit? Yes — no ballasts, no bulbs to replace, and the sealed housing shrugs off vibration and weather.

Questions? Call us at (833) 325-3250.
